85mm X 30mm Circle Stainless Steel Wire Mesh Washer Mesh Opening : 2mm X 3mm

85mm X 30mm Circle Stainless Steel Wire Mesh Washer Mesh Opening : 2mm X 3mm

wire mesh washer Ring information

Zhaotong has developed a wire mesh washer separation ring to provide a constant gap between two ceramic honeycomb tiles in a dual brick catalytic converter

Knitted Mesh Separation Ring Characteristics

Use metal braided mesh isolation ring to ensure consistent clearance and prevent gas erosion of expansion pad.

wire mesh washer Benefits

Suitable for round or oval shape

Easy to install

More cost-effective than other solutions

Man-made materials, such as ceramic yarns, can be woven together with wire to improve sealing and further reduce the possibility of gas bypasses

Available in materials suitable for temperatures over 1000°C

Material suitable for wire mesh washer

1. stainless steel

Describe

It is a mild steel, a ferroalloy containing at least 10.5% chromium that has been passivated to form an inert, microscopic thin, self-healing protective film.

Features

Stainless steels are noted for their excellent resistance to contamination and corrosion (rust) in wet environments -- properties that increase with chromium content. The material is resistant to high temperatures and has a high gloss and 100% recyclability, while being easy to disinfect and steam clean.

Application

Ideal for applications requiring high temperature, strength and corrosion resistance. Typical applications include harsh environments encountered in the automotive and aerospace industries, and the material is also well suited for sanitary applications in the medical, pharmaceutical and food processing/catering industries. Customers can choose from a variety of wires with different diameters, elasticity, thermal expansion, electrical conductivity, etc.

2. galvanized steel

Describe

Galvanizing is the process of applying a protective coating (usually zinc) to steel or iron to prevent it from rusting. The process involves electrically depositing, for example, zinc onto the surface of a steel wire. The coating acts as a sacrificial barrier that can slow or prevent corrosion.

Features

Galvanized steel has all the physical strength and elastic characteristics of carbon steel, but with a protective coating that provides enhanced corrosion resistance.

Application

Used where corrosion resistant steel is required for strength and reliability and the price is much lower than the cost of stainless steel alternatives. Typical applications are in the foundry industry and food processing as grease filters and disposable scrubbing products.

3. Nickel mesh

Describe

Nickel is a versatile element that can be alloyed with most metals and has complete solid solubility between nickel and copper. It is usually called nickel alloy.

Features

Nickel alloys exhibit high levels of corrosion resistance (especially to seawater) and high strength at high temperatures. Nickel has a special magnetic property and is often used as a coating or alloy to protect other metals.

Application

Nickel can withstand very harsh conditions. Typical applications include conductive pads in electrochemical equipment, electrical connections and seals in offshore engineering, and high temperature vibration resistant components used in gas turbines.

Knitted Mesh Separation Ring Specifications

Pictures show
